Operation Guidance

1. Open rear gate by removing both drop pins and position crane forks central to the cage and at maximum spread.
2. Position the pallet fork attachment into dedicated fork slot until fully engaged.
3. Close and lock gate ensuring that both safety pins are securely in place.
4. Attach pallet forks to lifting hook to commence lift.
5. The attachment is now ready to use with the assistance of banksman.
6. Once the load is positioned in its desired safe location, detach the lifting hook which allows the cage to be emptied safely.
7. Personnel can now empty the cage of produce by pulling back both shoot bolts on the front half drop gate.
8. Once emptied close front half drop gate and ensure shoot bolts are secure.
9. Lift Pallet forks & cage to be re-loaded

If cage needs to be left in place and Pallet forks Removed
10. Open rear gate by removing both drop pins
11. Slide out pallet forks from the dedicated fork slot
12. Close rear gate and secure in place with both drop pins
13. The cage and pallet forks are now ready to be used separately
